ELG9000-RC2
Paper Ticket Dispenser
Main features
- Stepping motor and photosensors ticket positioning
- Side frame supporting contactless and thermal printer modules
- Contactless Card Management based on Mifare Standard ISO/IEC 14443 A/B + ISO15693
- Double feeder capability
- Microprocessor based electronics
- Fan-folded pack or reel form handling
- Cutter blades with keen self-sharpening
- Error card capture function
- Ticket validation capability
- Real clock & calendar
- SMD low consumption electronic circuits
- Communication by means of RS232, USB and ethernet (optional)
- Overall description
- Card/Ticket specifications
- Environmental
- Thermal printer
Outline dimensions
168(H) x 268(L) x 129(W) mm
Weight
3.5 Kg (Approximately)
Electronics
Specific PCB
Processing capability
Fan-folded pack or reel
Stacker capacity
150/300/500/600/1000 pcs
Ticket generation
Driven cutter with rotary blade
Ticket motion
Stepping motor
Transport method
Rolls
Ticket sensors
Photosensors
Contactless
Mifare standard
Output interface
RS232/RS485/USB
Power requirements
+24V DC +/-10% 10A
Paper
Thermal paper
Length
85.60 mm
Width
53.98 mm
Thickness cutting validation
From 0.15 to 0.30/1.00 mm
Operating temperature
From -10 to + 60°C
Storage temperature
From -20 to + 65°C
Relative humidity
From 20 to 80%
Printing method
Thermal
Print width
48 mm
Dot size
0.125(X)*0.130(Y) mm (8dots/mm)
Dot pitch
0.125 mm (8 dots/mm)
Force on print line
1.5-2.0 Kg
Heat pulse life
1 x 10^8 pulses
Abrasion life
100 km
